Series reactor

Reactor – An effective harmonic current limiting solution for capacitor banks

BTB Electric capacitor reactors are designed with various impedance ratios to effectively mitigate harmonic currents at common harmonic orders in power systems.

Featuring a specialized construction, the reactors offer high magnetic saturation tolerance and exceptional operational performance. They are equipped with high-grade insulation in the magnetic circuit, combined with over-temperature protection and low power loss, ensuring long-term durability and system stability.

• Power range: 10~100kVAr
• Rated voltage: 240~525V
• Impedance ratio: 6, 7, 13, 14%
• Special design with high-level saturation
• Superior performance
• High-Grade laminations in magnetic circuit
• Easy pad termination & mounting
• Low power losses
• Protection from excess temperature
